Snapshot Details
- Brand: Villageboom GmbH
- Product Name: Villageboom High Power +
- Model Number: VB-5W-1L
- PV Module Maximum Power [W]: 5.2
- Number of Light Points: 1
- Main Unit Battery Chemistry: Li-ion
- Certification Expiration Date: 6/30/2023
Product Information
- Brand Villageboom GmbH
- Product Name Villageboom High Power +
- Model Number VB-5W-1L
- Product Type
Type of product dependent on the PV module maximum power where pico products are less than or equal to 10 W and solar home system kits are greater than 10 W up to 350 W Pico PV - Power Supply Type of current and power the product operates with, e.g. alternating current (AC) or direct current (DC) DC
- PV Module Maximum Power [W] 5.2
- PV Module Separate or Integrated Is the PV module integrated with the system or separate? Separate
- Number of Light Points Number of light points included in the system including auxiliary lights (e.g. a torch). 1
- Dimensions [l*w*h in cm] Dimensions of entire product in package N/A
- Mass [g] N/A
- Warranty for Main Unit [months] 24
- Other Warranty Information A 24-month warranty covering manufacturing defects.
Features
- Pay-As-You-Go Option Does the product have a pay-as-you-go option? No
- Mobile Phone Charging Is the product able to charge a mobile phone? Yes
- Plug-and-Play Plug-and-play kits don't require tools at the time of installation, whereas non-plug-and-play products require connections. Yes
- Product Family A product family covers a set of interchangeable components which combine to make two or more complete kits. All components and systems listed are considered to have met the applicable quality standards. No
Appliances
- Advertised to Power TV Does the product advertise to power a TV on any consumer-facing information? No
- Advertised to Power Fan Does the product advertise to power a fan on any consumer-facing information? No
- Advertised to Power Radio Does the product advertise to power a radio on any consumer-facing information? No
Lighting Details
- Main Unit Light Output [lm] Light output for the main lighting unit on highest setting not including auxiliary lights with their own battery. 82
- Brightest Lamp Lumen Efficacy [lm/w] Lumen efficacy for brightest lamp included in the main unit on highest setting. 71
- Auxiliary Lamp Light Output [lm] Light output for the brightest auxiliary light with its own battery on highest setting. Not included
- Auxiliary Lamp Lumen Efficacy [lm/w] Lumen efficacy for brightest lamp auxiliary light with its own battery on highest setting. Not included
- Total Light Output [lm] Light output of all light points including main lighting unit and any auxiliary lights. 270
- Notes About Lighting Details Offers a torch setting through a second integrated light on the side.
System Performance
- Total Lighting Service [lumen-hours/solar-day] 1030
- Available Daily Electrical Energy [Wh/day] The available daily electrical energy generated by a system in a solar day is measured in watt-hours per day [Wh/day]. Based on an example use profile with all of the appliances advertised to run with system used simultaneously. 10
- Main Lighting Unit Solar Run Time Used Alone [hours] Run time for the main unit assuming 5kWh/m2/day with lights on the highest setting and without any other loads used during the run time. 8.7
- Main Lighting Unit Full Battery Run Time [hours] Full battery run time for the main lighting unit with lights on the highest setting. The run time is defined as the time until the output is 70% of the initial, stabilized output. Lighting full battery run time estimates do not account for mobile phone charging or other auxiliary loads. 3.8
- Notes About System Performance N/A
Main Unit Battery
- Main Unit Battery Chemistry Li-ion
- Main Unit Battery Voltage [V] 3.7
- Main Unit Battery Capacity [Ah] 5
Ports
- Number of USB Ports Not tested
- Number of Barrel Jack Ports Not tested
- Number of Cigarette Lighter Ports Not tested
- Other Ports and Number of Each Not tested
- Notes About Ports Can charge mobile phone from one USB 2.0 Type A port on solar panel
Testing Information
- Quality Standards The version of quality standards that the product was evaluated towards. Lighting Global Quality Standards
- Certification Status VeraSol Certified
- Certification Expiration Date [MM/DD/YYYY] Indicates the date that the product's certification validity ends. 6/30/2023
Manufacturer Information
- Contact Information ricke@villageboom.com
- Website www.villageboom.com
- Co-Branded Co-branded products reference the results of a fully-tested product and are the same product with a different brand name. No
- Notes About Co-Branding N/A
Other Notes
- Other Notes on Testing or the Product N/A
